Configuring the Infrastructure Management Server to Oracle database communication to enable TLS 1.2 - Documentation for TrueSight Operations Management 11.3.07

Stop the Infrastructure Management Server by running the following command:

pw system stop

Go to the <Infrastructure Management Server Install Directory>\pw\pronto\bin directory, and run the switchTLSMode.pl script as shown in the following code block:

#Syntax
perl switchTLSMode.pl -<on/off> -flow <communication channel> -dbport <Oracle Database port> -dbver <Oracle Database version>
#Example
perl switchTLSMode.pl -on -flow oracle -dbport 2484 -dbver 19C

Parameter description

The following notes describe the key parameters used in the preceding command:

• -on/off: on option enables TLS mode of communication. off option disables TLS mode of communication and enables the default tcp/ssl mode of communication.
• -flow: This variable can have two options: event_and_data, and oracle. If flow is set to oracle, the communication between the Infrastructure Management Server and the Oracle database is TLS 1.2 enabled.
• -dbport: Specify the port number that is configured for the Oracle database communication.
• -dbver: Specify the Oracle database version. There are two compatible Oracle database versions: 12C, 19C

Open the pronet.conf file in the <Infrastructure Management Server Install directory>\pw\custom\conf directory, and verify that the configuration parameters are set as shown in the following code block:

pronet.api.database.portnum=2484
#Configuration settings to make TLS compliant
pronet.api.database.conntype=ssl

Verify that the latest oracle JDBC driver ojdbc8.jar is copied in the <Infrastructure Management Server Install directory>\pw\apps3rdparty\jdbc directory.

Run the following command to verify if the Infrastructure Management server is able to establish a connection with Oracle database in TLS mode:

#Microsoft Windows
<Infrastructure Management Server Install directory>\pw\pronto\bin\runjava api.database.DbUpCheck
#Linux
<Infrastructure Management Server Install directory>/pw/pronto/bin/runjava api.database.DbUpCheck
#Example output
INFO 06/08 21:14:34 Library 600002 Setting SSL properties for Oracle database connection
success

Start the Infrastructure Management Server by running the following command:

pw system start

Run the following command to verify if the Infrastructure Management server is able to establish a connection with Oracle database:

pw p l
#Example Output
BMC TrueSight Infrastructure Management Command Line Interface 2020 version 11.3.04
Copyright
1997-2020 BMC Software, Inc. as an unpublished work. All rights reserved.
Servers/Daemon Processes
------------------------
services 15788
httpd 9024
jserver 9812
pronet_agent 12860
pronet_cntl 13364
tunnelproxy 14352
rate 10292
Oracle
Running on test-bmc-setup:2484
mcell 1788

After restarting, the Infrastructure Management server status must be displayed as connected in the associated Presentation Server.
