Walkthrough: Provisioning Microsoft Windows 2012 on a bare metal machine - Documentation for TrueSight Server Automation 22.2

 ProcedureExample screen1

Add a DataStore.

1. Select Configuration > Property dictionary view.
2. Expand Built-in Property classes > Datastore and select Pxe datastore.
3. Click the Instances tab in the right pane.
4. Click the Add icon .
5. Enter details for Name and Description.
6. Enter values for the LOCATION, USERNAME, PASSWORD, FULL_PATH, and VIRTUAL_DIR properties.
7. Click Finish.



2

Add a device.

The Add Device panel lets you specify the MAC address of the new device.

1. In the Folder pane, select BladeLogic > Device.
2. Right-click and select Add device.
3. On the Add Device panel, enter a MAC Address and a short description, select the architecture and boot image, and for Provisioning Method select PXE.
4. Click Finish.

3Configure the Provisioning Manager.

1. Select Configuration > Provisioning Configurations > System Package Types.
2. Select Windows Server 2012 R2 Standard x64 and click the Edit icon in the upper right corner.
3. Set the appropriate System package type details:
   • Architecture
   • Installer location
   • RSCD Installer location
   • Initial partition size.
4. Click OK to save the changes.

4

Create a Microsoft Windows Server 2012 system package

1. Create a folder in the Depot for system packages. You must create system packages in the Depot folder.
2. Right-click the depot folder you created and select New > Depot Folder.
3. Name the new folder Provisioning and click Finish.
4. Right-click the Provisioning folder and select New > System Package.
5. Continue the system package creation process for specific operating systems.

5

Complete the General tab:

1. Name: Provision Windows 2012 R2
2. System package type: Windows Server 2012 DataCenter x64.
3. Click Finish. The System Package opens in a tab at right. Specify values for the system package in the following steps.

6

Complete the Disk Partition tab:

1. Click the Disk Partition tab (at the bottom of the window).
2. To add a new partition, click the Add icon .
3. Provide details in the following fields:
   • Label: C
   • Primary partition
   • Type: NTFS
   • Size (MB): 20000
4. Click OK.

5. If you have EFI-based hardware on the server that you are provisioning and you want to enable booting using Unified Extensible Firmware Interface (UEFI) during provisioning (rather than using BIOS), you must define a UEFI partition, in addition to the primary partition. Support for UEFI booting is provided in TrueSight Server Automation as of version 8.7. For a UEFI partition, perform the following steps:

   1. Click the Add icon .
   2. Provide the following details.

      • Label: D
      • EFI partition.
        In response to this selection, you are asked to confirm that you want to boot the target using UEFI.
      • Type : FAT32
      • Size (MB): 200
This is the default value. You can use any value between 50 and 250 megabytes.

   3. Click OK.

7

Complete the Basic Configuration tab:

1. Click the Basic Configuration tab.
2. Computer name: win2012r2
3. OM server name: Enter the name for this server that is displayed in the Console.
4. Administrator password: Enter the password for the local administrator of the server being provisioned.
5. Windows server domain: Enter the name of your Windows domain, such as production.
6. Select Create a computer account in the domain.
7. User name: Enter a user account that has permissions to add a computer to the domain.
8. Password: Password for the user account just entered.

8

Complete the Computer Settings tab:

1. Click the Computer Settings tab.
2. Name: Enter your name.
3. Organization: Enter your organization name.
4. PnP driver paths: Enter the location of plug-and-play (PnP) drivers and mass storage drivers in your data store. The path is relative to the root of the data store.
5. License key: Enter your license key. (To encrypt this value, use the Add Property feature in the console to create a new property of type encrypted string, add the license key as the property value, and use the property name here.) When you are provisioning Windows 2012, you are prompted to enter the License key. Enter the CD key in the License key field. It is mandatory to provide the CD key when you are provisioning Windows 2012.
6. Select Per seat or Per Server and supply the number.
7. Time Zone: Set as necessary.

9

Complete the Local Properties tab:

1. Click the Local Properties tab.
2. Double-click DATA_STORE
3. Select Use this default value.
4. Click the browse button and select a Windows instance. Then click OK.
5. To save and close the System Package, close the tab in the upper left corner of the pane. You are prompted to save the system package.

10

Create the Provision Job.

1. Create a subfolder in the Jobs folder.
2. Right-click the subfolder and select New > Provision Job > Windows Provision Job.
3. A wizard creates a new job and helps you select a system package, a device, and a data store.

11

Complete the Provision Job - General panel:

1. Enter a job name.
2. Select a job folder.

Use the defaults for all other settings.

12

Complete the Provision Job - System Package Properties panel:

1. In the Path to system package field, click the browse button to choose the system package created in earlier steps.
2. In Property Settings, select the data store.

Use the defaults for all other settings.

13

Complete the Provision Job - Devices to provision panel:

1. For Associated boot image, select the boot image.
2. In the Devices to provision section, click the Add icon and select the device to provision.

Use the defaults for all other settings.

14

Complete the Provision Job - Schedules panel:

Check the Execute job now option to trigger immediate execution when you finish defining the Provision job.

15

Complete the Provision Job - Permissions panel:

1. Add a job permission, as shown.
2. Use the defaults for all other settings.
3. Click Finish.

The Provision job executes immediately. The job is stored in the Jobs folder.
