REST constraints - Documentation for BMC Release Process Management 5.0.07

GET /v1/constraints

Returns all the constraints (unarchived by default).

Filters

• constraint — Complex filter by constraint (by ID and type; only supported type is ‘RouteGate’). See sample below.
• governor — Complex filter by governor (by ID and type; only supported type is ‘PlanStageInstance). See sample below.
• route_id — Integer for route ID
• constrainable_type – String for constrainable type (currently only ‘RouteGate’ supported)
• active — Boolean value for showing active (on by default, can be combined with inactive to show both)
• inactive — Boolean value for showing inactive (can be combined with active to show both)

Common attributes

• format — Ensure to include an accept header or add .xml or .json to the last path element
• token — Your API Token for authentication

Errors caused

• ERROR 403 Forbidden — Occurs when the token is invalid
• ERROR 404 Not Found — Occurs when no records are found

Examples

To test this method, insert this URL or your valid API key and application host into a browser or HTTP client like wget or curl. For example:

curl -i -H "accept: text/xml" -X GET

curl -i -H "accept: application/json" -X GET

An example of filters:

curl -i -H "accept: application/json" -H "Content-type: application/json" -X GET -d '{ "filters": { "name":"Dev" } }'

An example of filters with constraint:

curl -i -H "accept: application/json" -H "Content-type: application/json" -X GET -d '{ "filters": { "constraint": { "id":1, "type":"RouteGate" } } }'

An example of filters with governor:

curl -i -H "accept: text/xml" -H "Content-type: text/xml" -X GET -d '<filters><governor><id>1</id><type>PlanStageInstance</type></governor></filters>'

GET /v1/constraints/[id]

Returns a constraint by the ID.

Common attributes

• id — Numerical unique ID for record
• format — Ensure to include an accept header or add .xml or .json to the last path element
• token — Your API Token for authentication

Errors caused

• ERROR 403 Forbidden — Occurs when the token is invalid
• ERROR 404 Not found — Occurs when record to show is not found

Examples

To test this method, insert this URL or your valid API key and application host into a browser or HTTP client like wget or curl. For example:

curl -i -H "accept: text/xml" -X GET

curl -i -H "accept: application/json" -X GET

POST /v1/constraints

Creates a new constraint from the posted data.

Required attributes

• constrainable_id — Integer for constrainable ID (currently route gate ID)
• constrainable_type — String for constrainable type (currently only ‘RouteGate’ supported)
• governable_id – Integer for governable ID (currently plan stage instance ID)
• governable_type — String for governable type (currently only ‘PlanStageInstance’ supported)

Optional attributes

• active – Boolean value that indicate if constraint active or not

Common attributes

• format — Ensure to include an accept header or add xml or .json to the last path element
• token — Your API Token for authentication

Errors caused

• ERROR 403 Forbidden — Occurs when the token is invalid
• ERROR 422 Unprocessable entity — Occurs when validation fails, objects and errors are returned
• ERROR 500 Internal Server Error — Occurs when server error(s) occurred, , objects and errors are returned

Examples

To test this method, insert this URL or your valid API key and application host into a browser or HTTP client like wget or curl. For example:

curl -i -H "accept: text/xml" -H "Content-type: text/xml" -X POST -d '<constraint><constrainable_id>1</constrainable_id><constrainable_type>RouteGate</constrainable_type <governable_id>1</governable_id><governable_type>PlanStageInstance</governable_type></constraint>'

curl -i -H "accept: application/json" -H "Content-type: application/json" -X POST -d '{"constraint": { "constrainable_id":1, "constrainable_type":"RouteGate", "governable_id":1, "governable_type":"PlanStageInstance" }}'

PUT /v1/constraints/[id]

Updates an existing constraint with values from the posted document

Editable attributes

• constrainable_id — Integer for constrainable ID (currently route gate ID)
• constrainable_type — String for constrainable type (currently only ‘RouteGate’ supported)
• governable_id – Integer for governable ID (currently plan stage instance ID)
• governable_type — String for governable type (currently only ‘PlanStageInstance’ supported)
• active — Boolean value that indicate if constraint active or not

Common attributes

• format — Ensure to include an accept header or add .xml or .json to the last path element
• token — Your API Token for authentication

Errors caused

• ERROR 403 Forbidden — Occurs when the token is invalid
• ERROR 404 Not found — Occurs when record to update is not found
• ERROR 422 Unprocessable entity — Occurs when validation fails and objects and errors are returned
• ERROR 500 Internal Server Error — Occurs when server error(s) occurred and objects and errors are returned.

Examples

To test this method, insert this URL or your valid API key and application host into a browser or HTTP client like wget or curl. For example:

curl -i -H "accept: text/xml" -H "Content-type: text/xml" -X PUT -d '<constraint><active>false</active></constraint>'

curl -i -H "accept: application/json" -H "Content-type: application/json" -X PUT -d '{ "constraint": { "active" : false }}'

DELETE /v1/constraints/[id]

Deletes a constraint.

Common attributes

• id — Numerical unique ID for record
• format — Ensure to include an accept header or add .xml or .json to the last path element
• token — Your API Token for authentication

Errors caused

• ERROR 403 Forbidden — Occurs when the token is invalid
• ERROR 404 Not found — Occurs when no records are found

Examples

To test this method, insert this URL or your valid API key and application host into a browser or HTTP client like wget or curl. For example:

curl -i -H "accept: text/xml" -X DELETE

curl -i -H "accept: application/json" -X DELETE

Sample output

The following JSON is a sample output from GET /v1/constraints:

HTTP/1.1 200 OK
Server: Apache-Coyote/1.1
X-UA-Compatible: IE=Edge
ETag: "e12d69a32321c0ee192b2167a7cf5c35"
Cache-Control: max-age=0, private, must-revalidate
X-Request-Id: 608c06b24ba5ff4127ca86b7da6647c5
X-Runtime: 1.575000
Content-Type: application/json;charset=utf-8
Content-Length: 969
Date: Fri, 23 Aug 2013 12:52:50 GMT
[{	"active":true,	"constrainable_id":3,	"constrainable_type":"RouteGate",	"created_at":"2013-08-23T12:26:52-04:00",	"governable_id":3,	"governable_type":"PlanStageInstance",	"id":1,	updated_at":"2013-08-23T12:26:52-04:00"
}, {	"active":true,	"constrainable_id":3,	"constrainable_type":"RouteGate",	"created_at":"2013-08-23T12:27:50-04:00",	"governable_id":2,	"governable_type":"PlanStageInstance",	"id":3,	"updated_at":"2013-08-23T12:27:50-04:00"
}, {	"active":true,	"constrainable_id":2,	"constrainable_type":"RouteGate",	"created_at":"2013-08-23T12:27:55-04:00",	"governable_id":1,	"governable_type":"PlanStageInstance",	"id":4,	"updated_at":"2013-08-23T12:27:55-04:00"
}, {	"active":true,	"constrainable_id":2,	"constrainable_type":"RouteGate",	"created_at":"2013-08-23T12:28:01-04:00",	"governable_id":2,	"governable_type":"PlanStageInstance",	"id":5,	"updated_at":"2013-08-23T12:28:01-04:00"
}]

The following XML is a sample output from GET /v1/constraints/1:

HTTP/1.1 200 OK
Server: Apache-Coyote/1.1
X-UA-Compatible: IE=Edge
ETag: "77deefc8e8767bb6b7c635bbab0bdab2"
Cache-Control: max-age=0, private, must-revalidate
X-Request-Id: 397d5f0810e1408e5dd8c17240c8fd36
X-Runtime: 0.882000
Content-Type: application/xml;charset=utf-8
Content-Length: 498
Date: Fri, 23 Aug 2013 12:54:15 GMT
<?xml version="1.0" encoding="UTF-8"?>
<constraint> <active type="boolean">true</active> <constrainable-id type="integer">2</constrainable-id> <constrainable-type>RouteGate</constrainable-type> <created-at type="datetime">2013-08-23T12:27:55-04:00</created-at> <governable-id type="integer">1</governable-id> <governable-type>PlanStageInstance</governable-type> <id type="integer">4</id> <updated-at type="datetime">2013-08-23T12:27:55-04:00</updated-at>
</constraint>
